NSR7500X-04E MPLS Core Router
NSR7500X-04E MPLS core router further implements «multicore power» on the basis of the leading «dual-core power». Based on the ATCA structure design and meeting the users’ high-performance requirements, it provides the most complete dual-redundancy or multi-redundancy design for the whole system, providing users with the high reliability of enterprise-class.
With unified MyPower-R software, NSR7500X-04E core router provides abundant routing, backup, network security services, IP multicast, QoS, network management, and other functions, supports a variety of network layer and link layer protocols, supports BGP border gateway protocol and MPLS function, and can play the PE node function in enterprise network.
As a multi-purpose universal data processing and routing platform, NSR7500X-04E core router can cooperate with a full range of Maipu routers to provide operators, government, finance, energy, transportation, education, military and other industrial users and large/medium-sized enterprise users with a full range of WAN solutions, widely applied at the core backbone layer and core aggregation layer of the above industries. NSR7500X-04E core router is the next generation version of NSR7500X which was widely deployed in many countries.
NSR7500X-04E core router has two models. It has two main control slots, two switching fabric slots, 4 service slots, adopts the multi-core processor to realize the distributed forwarding architecture, and supports 40G/10G/1G and E1/CE1/POS/CPOS TDM interfaces.
(Note: The product information may not be latest. For the latest, please contact overseas@maipu.com)
Product Features
Flexible uplink link
NSR7500X-04E core router support four kinds of high-performance multi-core SPU module for customers real requirements; meanwhile, NSR7500X uplink supports various mainstream WAN access link technologies, such as 1G/10G/40G Ethernet, E1/CE1, POS/CPOS, etc.
More than eight expansion slots
NSR7500X-04E core router is modular design which has rich expansion slots. The whole device supports 4 extended slots totally. The strong expansion ability can provide high-density access and protect customer investment.
High performance
NSR7500X-04E core router supports high performance and the configured ACL, QoS, have small influence for the forwarding performance. And customer can also upgrade the performance by changing SPU service engines.
Advanced Secure service
NSR7500X-04E core router has high performance VPN aggregation function. Meanwhile, the device data can be transmitted in the secure MPLS/VPLS, IPsec, GRE, L2TP tunnel, preventing the data from being accessed and tampered and providing the higher security for the application over the network.
Segment routing technologies
NSR7500X-04E core router fully supports SRv6 segment routing technology, supports IFIT in-flow detection, FlexE network slicing, channelized sub-interfaces, and other advanced SRv6 features. It also supports the tuning capabilities of SRv6 Policy based on latency, bandwidth, and packet loss rate, as well as the function of SRv6 Policy fault escape to SRv6 BE.
Rich software features
NSR7500X-04E core router provides rich software features; supports various application technologies, such as IPv4/IPv6, VPN, MPLS, multicast, ACL, MAC address binding, access control, bandwidth limitation, MSTP, and NAT; supports RSVP resource reserving protocol and CAR; provides hierarchical QoS function to ensure the high priority of the key services; support the queue management policies, such as FIFO, PQ, CQ, FQ, WFQ, CBWFQ, and LLQ.
Rich Management modes
NSR7500X-04E core router supports complete management modes, including SNMPv1/v2c/v3, CLI, USB drive deployment, MIB, RMON, SYSLOG, TR069, IPFIX, etc. Combine with Maipu SNMP Management Platform, it can provide the simple and easy-to-use remote network management.
